Gluu 4.3 supports Apple platform FIDO 2 / WebAuthn authenticators like TouchID

The first laptop to build-in FIDO was the Google Pixelbook (RIP). It was a little geeky–you enabled a hidden ChromeOS feature to activate FIDO U2F via the laptop power button. But Apple has taken this behavior to its logical next level: using the MacBook Touch ID as a FIDO token. Who needs to plug in a biometric USB token when you have a fingerprint reader right on your keyboard?

Apple joined the FIDO Alliance back in early 2020. One of the goals was to add “platform authenticator” capabilities to their devices. iOS 14 and new MacBooks (like the M1) are the first to do so, paving the way for phishing-resistant, standards-based passwordless two-factor authentication.

Some organizations resist issuing USB or bluetooth hardware devices.  Platform authenticators offer the advantages of FIDO 2 / WebAuthn, without the need to buy a physical token.

Touch ID on a web app uses a standard called W3C Web Authentication (WebAuthn) which defines a “promise-based” javascript API for the creation (i.e. enrollment or registration) and use (i.e. authentication) of credentials based on public key cryptography. The W3C WebAuthn Working Group was formed to produce a new specification that can be implemented by all browsers (for desktops and mobiles) and that remains interoperable.

Apple Anonymous attestation

“Attestation” (performed in the FIDO2 server during creation) is basically a secure way for you to verify the device is authentic and has the capabilities it says it does. A limitation of attestation is that it does not guarantee that the operating system running on that device has not been tampered. Non-platform credentials (e.g. a USB token) does not have this issue, because it is impossible (or at least impractical) to modify the hardware.  An untampered operating system ensures that the private key is protected by the Secure Enclave, protected with Face ID or Touch ID (although passcode back stops biometric failure).

Apple Anonymous Attestation is first of its kind, providing a service like an Anonymization CA, where the authenticator works with a cloud operated CA owned by its manufacturer to dynamically generate per-credential attestation certificates such that no identification information of the authenticator will be revealed to websites in the attestation statement. Furthermore, among data relevant to the registration ceremony, only the public key of the credential along with a hash of the concatenated authenticator data and client data are sent to the CA for attestation, and the CA will not store any of these. This approach makes the whole attestation process privacy preserving. In addition, this approach avoids the security pitfall of Basic Attestation that the compromising of a single device results in revoking certificates from all devices with the same attestation certificate.

For more information about Apple’s implementation of FIDO, you can watch Apple’s only presentation for implementing Touch ID as a Fido 2 device and read this blog


Gluu Support for WebAuthn / FIDO 2 credentials

Support for Apple platform FIDO credentials is available in Gluu Server 4.3.

Gluu’s support for FIDO is multi-tiered. The Gluu Server includes a standalone FIDO server which validates and registers credentials.  There is a Casa FIDO plugin to enable users to manage their devices (i.e. register, remove). And Gluu provides a FIDO SCIM extension, which enables applications to list and remove FIDO devices for an end-user (enabling self-service).

The Gluu OpenID Connect server enables the use of FIDO for traditional two-step authentication (step 1: username/password; step 2: FIDO device authentication) or a passwordless flow (step 1: username; step 2: FIDO device authentication).

All this is great news for the industry. Reducing the password-monoculture will make the Internet safer for everyone. A decade of hard work by the FIDO community is helping to make this happen, and enabling Gluu to bring these new features to the open source community.
